WIRING - SYSTEM CIRCUIT DIAGRAM 71-143

NO. Ref. wiring harness NO. Ref. wiring harness
D018 Floor harness D016 Floor harness

Front instrument
C013 D017 Floor harness
harness

: connectors between wiring harnesses

NO. Ref. wiring harness
NO.
(connector position)
Engine compartment harness
and front instrument harness
A306 C105
(left side of instrument
crossbeam)
Engine compartment harness
71
and front instrument harness
A301 C101
(left side of instrument
crossbeam)
Floor harness and front
D301 C401 instrument harness （under
the left A column)
Floor harness and front
D201 C301 instrument harness （under
the left A column)

Front instrument harness and
engine compartment harness
C203 A303
(left side of instrument
crossbeam)

Floor harness and front
D205 C305 instrument harness （under
the left A column)

: Earthing

NO. Earth point NO. Earth point

Left of combination Under passenger's
B2 F1
instrument seat
Right of combination Right of engine
B3 A7
instrument compartment
