WIRING - DISCRIPTION OF HARNESS CONNECTORS 71-205

C401 To floor harnesses 1&2

NO. Color Function Remark NO. Color Function Remark
Right rear
Left rear door un- Blue -
1 Blue 20 wheel speed
lock + black
sensor power
71
Acceleration
Left rear door Brown -
2 Brown 21 sensor earth-
lock + yellow
ing
Brown - Green - Acceleration
3 Rear defrost 22
yellow yellow sensor signal
White - Hand brake Purple - Acceleration
4 23
black switch yellow sensor power

Black - Red -
5 Earthing 24 CAN H
blue white
DPF pressure Blue - yel-
6 Orange 25 CAN L
sensor signal low
DPF pressure Blue - yel-
7 Brown 26 CAN L
sensor power low

Red - Fuel sensor sig- Red -
8 27 CAN H
blue nal white
Left rear steer-
Green- Temperature sen-
9 28 Green ing lamp power
red sor signal
supply
Gray - Normally open
10 White-red CAN2–H 29
white contact -

Reversing
DPF pressure
11 Sky blue 30 Yellow lamp power
sensor ground
supply
Tire pressure
Red - Rear fog lamp
12 Pink monitoring mod- 31
white power
ule power supply
13 Yellow Tire pressure 32 Green-red Left rear
