PRIME B460-PLUS

Intel Chipset

Motherboards
Motherboards

CPU LGA1200 Chipset Intel® B460
DDR4 2933/2800/2666 PCIE 3.0 x16 1 x PCIe 3.0 x16 slot (supports x16 mode)
1 x PCIe 3.0 x16 slot (max. at x4 mode)

LAN Realtek Gb LAN Audio 7.1-CH Audio

SPECIFICATIONS
Graphics Cards & PSUS
Graphics Cards & PSUS
CPU • Intel® Socket LGA 1200 for 10th Gen Intel® Core™, -3 x 4-pin Chassis Fan header
Pentium® Gold and Celeron® processors • Power related
• Supports Intel® 14nm CPU -1 x 24-pin Main Power connector
• Supports Intel® Turbo Boost Technology 2.0 and -1 x 8-pin +12V Power connector
Intel® Turbo Boost Max Technology 3.0* • Storage related
* Intel® Turbo Boost Max Technology 3.0 support depends -2 x M.2 slot (Key M)
on the CPU types. -6 x SATA 6Gb/s ports
Chipset • Intel® B460 Chipset • USB
Memory • 4 x DIMM, Max. 128GB, DDR4 2933/2800/2666/2400/2133 -1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2
Display
Display
MHz Non-ECC, Un-buffered memory* Gen 1 ports
• Dual channel memory architecture -2 x USB 2.0 headers support additional 4 USB 2.0 ports
• Supports Intel® Extreme Memory Profile (XMP) • Miscellaneous
• ASUS OptiMem -2 x RGB headers
* For 10th Gen Intel® processors, only Core™ i9/i7 CPUs -1 x Clear CMOS header
support 2933/2800/2666/2400/2133 natively, others will -1 x COM Port header
run at the maximum transfer rate of DDR4 2666MHz. -1 x Front Panel Audio header (AAFP)
* Refer to www.asus.com for the Memory QVL (Qualified -1 x S/PDIF out header
Vendors Lists). -1 x System panel connector
Graphics • 1 x D-Sub ASUS Special Features • ASUS 5X PROTECTION III
Networks
Networks
• 1 x DVI-D - ASUS DIGI+ VRM
• 1 x HDMI™ 1.4b - ASUS LANGuard
*Graphics specifications may vary between CPU types. - ASUS Overvoltage Protection
Expansion Slots • Intel® 10th Gen Processors - ASUS SafeSlot Core
-1 x PCIe 3.0 x16 slot (supports x16 mode) - ASUS Stainless-Steel Back I/O
• Intel® B460 Chipset • ASUS Q-Design
-1 x PCIe 3.0 x16 slot (max. at x4 mode) - ASUS Q-DIMM
-2 x PCIe 3.0 x1 slots - ASUS Q-Slot
-2 x PCI slots • ASUS Thermal Solution:
Multi-GPU Support • Supports AMD® 2-Way CrossFireX™ Technology - Aluminum heatsink design
Storage • Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports • ASUS EZ DIY:
• Intel® B460 Chipset - Box Headers
- M.2_1 slot (Key M) type 2242/2260/2280 (supports PCIE • ASUS Lighting Control
3.0 x 4 & SATA mode)* - Standard RGB headers
ODD & Storage
ODD & Storage
- M.2_2 slot (Key M) type 2242/2260/2280/22110 (supports Software Features <ASUS Exclusive Software>
PCIE 3.0 x 4 mode) • Armoury Crate
- 6 x SATA 6Gb/s ports • AI Suite 3
• Intel® Rapid Storage Technology supports Raid 0,1,5,10 -Performance And Power Saving Utility
• Intel® Optane™ Memory Ready* -EPU
• When a device in SATA mode is installed on the M.2_1 -Digi+ VRM
socket, SATA6G_1 port cannot be used. -Fan Xpert 2+
*Only the M.2_2 socket can support Intel® Optane™ memory. -EZ Update
Ethernet • 1 x Realtek RTL8111H 1Gb Ethernet ASUS LANGuard -ASUS CPU-Z

USB • Rear USB (Total 6 ports) -AI Charger
- 4 x USB 3.2 Gen 1 ports (4 x Type-A) -DAEMON Tools
- 2 x USB 2.0 ports (2 x Type-A) -Norton Anti-virus software (Free Trial for 60 days)
• Front USB (Total 6 ports) -WinRAR
- 1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports <UEFI BIOS>

- 2 x USB 2.0 headers support additional 4 USB 2.0 ports • ASUS EZ DIY
Audio • Realtek ALC887 7.1-Channel High Definition Audio CODEC* - ASUS CrashFree BIOS 3
Server & Workstation
Server & Workstation
- Jack-detection, Multi-streaming, Front Panel Jack-retasking - ASUS EZ Flash 3
• Audio Features - ASUS UEFI BIOS EZ Mode
- LED-illuminated audio trace path design BIOS • 128 Mb Flash ROM, UEFI AMI BIOS
- Premium Japanese audio capacitors Manageability • WOL by PME, PXE
- Audio Shielding Accessories • Cables
- Dedicated audio PCB layers -2 x SATA 6Gb/s cables
* A chassis with an HD audio module in the front panel is • Miscellaneous
required to support 7.1-channel audio output. -1 x I/O Shield
Back Panel I/O Ports • 4 x USB 3.2 Gen 1 ports (4 x Type-A) -1 x M.2 SSD screw package
• 2 x USB 2.0 ports (2 x Type-A) • Installation Media
• 1 x D-Sub port -1 x Support DVD
• 1 x DVI-D port • Documentation
Mini / Stick PC
Mini / Stick PC
• 1 x Realtek RTL8111H 1Gb Ethernet port -1 x User’s manual
• 3 x Audio jacks Operating System • Windows® 10 - 64 bit
• 1 x HDMI™ port Form Factor • ATX Form Factor
• 1 x PS/2 Keyboard/Mouse combo port • 12.0 inch x 9.0 inch (30.5 cm x 22.86cm)
Internal I/O Connectors • Fan and cooling related

-1 x 4-pin CPU Fan header Note: The specifications are subject to changes without notice.
*Product specifications are subject to change without notice, although every effort is made to ensure that they are correct up to the point of launch.
Please contact your suppliers or local dealers for exact product launch schedules, specifications and availability.
