PRIME TRX40-PRO S PRIME X570-PRO

AMD Chipset AMD Chipset Motherboards Motherboards

CPU AM4 Chipset AMD X570
DDR4 4400+(O.C.) PCIe 4.0 x 16 3
USB 5 x USB 3.2 Gen 2 LAN Intel® I211AT Gigabit LAN Graphics Cards & PSUS
Storage 2 x M.2 Audio Realtek® S1220A

SPECIFICATIONS
Graphics Cards & PSUS
CPU • AMD AM4 Socket for 3 rd and 2 nd AMD Ryzen™ /2 nd and 1 st • AMD X570 chipset
Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors - 1 x USB 3.2 Gen 2 (up to 10Gbps) front connector
* Due to CPU limitation, CPU cores supported varies by - 4 x USB 3.2 Gen 2 (up to 10Gbps) ports
processors. (3*Type A+1*Type C at back panel)
** Refer to www.asus.com for the AMD® CPU support list. - 2 x USB 3.2 Gen 1 (up to 5Gbps) ports
Chipset • AMD X570 Chipset (2 ports at mid-board)
Memory • 3 rd Gen AMD Ryzen™ Processors - 4 x USB 2.0 ports at mid-board
- 4 x DIMM, max. 128GB, DDR4 4400(O.C.)/4266(O.C.)/ ASUS Special Features • 5-Way Optimization Display Display
4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/ - 5-Way Optimization tuning key perfectly consolidates
3466(O.C.)/3400(O.C.)/3200/3000/2933/2800/2666/2400/ TPU Insight, EPU Guidance, DIGI+ VRM, Fan Expert 4, and
2133 MHz, un-buffered memory Turbo App
• 2 nd Gen AMD Ryzen™ Processors - DIGI+ VRM: Digital power design with Dr. MOS
- 4 x DIMM, max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/ - Fan Xpert 4: Fan Auto Tuning function and multiple
3400(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800/2666/ thermistors selection for optimized system cooling
2400/2133 MHz, un-buffered memory control
• 2 nd and 1 st Gen AMD Ryzen™ with Radeon™ Vega Graphics - TPU Insight
Processors - EPU Guidance Networks Networks
- 4 x DIMM, max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/ - Turbo App: system performance tuning, network priority,
2933/2800/2666/2400/2133 MHz, un-buffered memory and audio scene configuration for selected applications
• Dual channel memory architecture • Armoury Crate
• ECC Memory (ECC mode) support varies by CPU • ASUS SafeSlot - Protect your graphics card Investment
* The maximum memory capacity supported vary • ASUS 5X Protection III
depending on the CPU you installed. ASUS Quiet Thermal • ASUS Fan Xpert 4

** Refer to www.asus.com for the Memory QVL Solution • Stylish Design: MOS Heat-sink with dual thermal pads

(Qualified Vendors List). design, PCH Fan,PCH and M.2 Heatsink
Expansion Slots • 3 rd Gen AMD Ryzen™ Processors Back Panel I/O Ports • 1 x PS/2 keyboard/mouse combo port
- 2 x PCI Express 4.0 x16 slots • 1 x DisplayPort
(single at x16 or dual at x8/x8 mode) • 1 x HDMI port
• 2 nd Gen AMD Ryzen™ Processors • 1 x Intel LAN (RJ45) port
- 2 x PCI Express 3.0 x16 slots • 3 x USB 3.2 Gen 2 (up to 10Gbps) ports (Type-A) ODD & Storage
(single at x16 or dual at x8/x8 mode) • 1 x USB 3.2 Gen 2 (up to 10Gbps) port (Type-C)
• 2 nd and 1 st Gen AMD Ryzen™ with Radeon™ Vega Graphics • 4 x USB 3.2 Gen 1 (up to 5Gbps) ports (Type-A)
Processors • 1 x Optical S/PDIF out
- 1 x PCIe 3.0 x16 slot (x8 mode) • 5 x Audio Jacks(Line in,Front Speaker Out,Mic in,Center/
• AMD X570 chipset Subwoofer,Rear Speaker Out)
ODD & Storage
- 1 x PCI Express 4.0 x 16 slot (max. at x4 mode) Internal I/O Connectors • 1 x USB 3.2 Gen 2 (up to 10Gbps) connector
- 3 x PCI Express 4.0 x1 slots • 1 x USB 3.2 Gen 1 (up to 5Gbps) connector support
Graphics • Integrated Graphics in the 2 nd and 1 st Gen AMD Ryzen™ additional 2 USB ports
with Radeon™ Vega Graphics Processors • 2 x USB 2.0 connectors support additional 4 USB ports
- Multi-VGA output support: DisplayPort/HDMI ports • 1 x M.2_1 Socket 3 for M Key, type 2242/2260/2280/22110
- Supports DisplayPort 1.2 with max. resolution of devices support, (both SATA & PCIE mode)
4096 x 2160 @60Hz • 1 x M.2_2 Socket 3 for M Key, type 2242/2260/2280/22110
- Supports HDMI 2.0b with max. resolution of devices support, (both SATA & PCIE mode)
4096 x 2160 @60Hz • 6 x SATA 6.0Gb/s connectors (gray)
Multi-GPU support • 3 rd and 2 nd Gen AMD Ryzen™ Processors • 1 x CPU Fan header (4-pin) for both 3-pin(DC mode) and Server & Workstation
- Supports NVIDIA® 2-Way SLI® Technology 4-pin(PWM mode) CPU coolers control with auto detection
- Supports AMD 3-Way CrossFireX™ Technology support
• 2 nd and 1 st Gen AMD Ryzen™ with Radeon™ Vega Graphics • 1 x CPU OPT Fan header (4-pin)
Processors • 1 x AIO Pump header (4-pin)
- Supports AMD 2-Way CrossFireX™ Technology • 1 x W_PUMP+ header (4-pin)
Storage • 3 rd Gen AMD Ryzen™ Processors • 1 x PCH _FAN connector (4-pin)
Server & Workstation
- M.2_1 socket 3 with M Key, Type • 3 x Chassis Fan connectors (4-pin) for both 3-pin(DC mode)
2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes) and 4-pin(PWM mode) coolers control with auto detection
storage devices support support
• 2 nd Gen AMD Ryzen™/2 nd and 1 st Gen AMD Ryzen™ with • 2 x Aura RGB headers
Radeon™ Vega Graphics Processors • 1 x addressable Gen 2 header
- M.2_1 socket 3 with M Key, Type • 1 x Front panel audio connector (AAFP)
2242/2260/2280/22110(PCIE 3.0 x4 and SATA modes) • 1 x SPI_TPM connector
storage devices support • 1 x COM connector Mini / Stick PC Mini / Stick PC
• AMD X570 Chipset: • 1 x 24-pin EATX Power connector
- M.2_2 socket 3 with M Key, Type 2242/2260/2280/22110 • 1 x 8-pin EATX 12V Power connector
(PCIE 4.0 x 4 and SATA modes) storage devices support • 1 x 4-pin EATX 12V Power connector
- 6 x Serial ATA 6.0 Gb/s connectors with RAID 0, RAID 1 and • 1 x System Panel Connector
RAID 10 support • 1 x Clear CMOS header
LAN • Intel® I211AT Gigabit LAN • 1 x Node Connector
Audio • Realtek® S1220A 8-channel high definition audio CODEC • 1 x Power-on button
featuring Crystal Sound 3 • 1 x T_Sensor Header
USB • 3 rd and 2 nd Gen AMD Ryzen™/2nd and 1 st Gen AMD Ryzen™ Form Factor • ATX Form Factor, 12”x 9.6” (30.5cm x 24.4cm)
with Radeon™ Vega Graphics Processors
- 4 x USB 3.2 Gen 1(up to 5Gbps) ports (4 ports at back panel) Note: The specifications are subject to changes without notice. Peripherals
