78 | ChapTER 3 The Basics of The ToolBox

Figure 3.12
The Move To 2nd option is
used in the array tool to set
a fixed distance between
instances: (a) setting the
array distance; (b) changing
the number of elements in
the array.

(a)

(b)

If you want to arrange elements in a fixed space and the exact spacing between elements
is less important, use the Move To Last option. Figure 3.13 shows an array where the location
of its last element was picked and the elements were placed equally between the first and last
elements. With this option, the length is fixed and the array squeezes elements within that
constraint as the number changes.

Figure 3.13
This array uses the Move To
last option and fills instances
between the first and last
instances: (a) creating an
array first to last; (b) adding
more elements to this array to (a)
keep the end element in the
same location but add more in
between.

(b)
