Guide Pins (with Collar)

Guide Pins (with Collar) – GDP-EC
Pernos guia con collar | Guias principais | Colonnes de guidage (avec épaulement) | Führungsbolzen (mit Bund)

INFORMATION KEY:
D = Pin Body Diameter 800-1100 N/mm 2 (Ref. Only ~27±5 HRC)
E = Shoulder Diameter
H = Head Diameter K 60 ± 2 HRC
K = Head Thickness
N = Pin Body Length k6
g6
S = Shoulder Length Ø H Ø E Ø D
T = Collar Length Ø E e7
Standard: Euro-Series
Material: 1 .7131 (AISI 5115 Type) Steel 4 (Ø D = 9-15)
Surface Treatment: Case Hardened T -0.5
Surface Finish Definitions: See Appendix E* S -1 N
Fit Tolerances: See Appendix F*
Dimensions: Shown in Millimeters (mm)
*See Technical Reference Information at www .dme .net

ITEM N
PREFIX D E H K T S 020 025 030 035 045 050 055 060 065 070 075 085 090 095 105 110 125 135 145 150 155 165
012
017
09 022
GDP-EC
(R02)* OR 14 16 3 3 027
10 036
046
056
017
022 Die Components – Euro-Series | Guide Pins (with Collar)
027
036
14 046
GDP-EC
(R02)* OR 20 25 6 9 056
15 066
076
086
096
116
* “(R02)” is only a cross-reference to current D-M-E Europe Catalog item prefix numbers .

HOW TO ORDER: Specify Item Number with prefix, D diameter, S length, and N length . Include zeros KEY TO CHART
and dashes but omit decimals, as shown . Items in stock
Example: Example:
Prefix D S N
Prefix D S N Prefix D S N 2-3 week delivery
GDP-EC - - - GDP-EC-09-027-020 GDP-EC-14-066-055
Contact D-M-E
for quote

For Surface Finish Definitions and Fit Tolerances, see Appendices E and F
from the Technical Reference Information PDF found at www.dme.net
