PDE2600PNUK
Parker Pneumatic Origa OSP-E Electric Linear Actuators

Trapezoidal screw actuator with internal plain
bearing guide for intermittent applications

A completely new generation of actuators which can be integrated into any
machine layout neatly and simply.

Advantages Features
• Accurate path and • Integrated drive and
position control guidance system
• High force output • Complete motor and
control packages
• Self-locking
• Diverse range of accessories
• Excellent slow speed
characteristics and mountings
• Special options available Low friction
• Easy installation support rings
• Low maintenance
Threaded holes
• Ideal for level regulation,
lifting and other applications
with intermittent operations Carrier

Double row Corrosion resistant
angular steel sealing band
contact ball
bearings

Slotted profile with
dovetail grooves

Permanent magnet
for contactless
sensing
Plastic nut
Take the easy route and load
Trapezoidal all the dimensions into your
screw system. The file is suitable
End cap screws for all current CAD systems –
with threaded available on CD-Rom or at
mounting holes www.parker-origa.com
Drive
shaft Heavy Duty guide SLIDELINE
HD linear guides Combination with
for heavy duty sliding guide for
The dovetailed mounting rails applications heavy-duty
of the new actuator expand its operation
function into that of a universal
system carrier.
Modular system components SFI-plus POWERSLIDE
are simply clamped on.
displacement Roller bearing
measuring system precision guidance
for smooth travel
and high dynamic
or static loads.
PROLINE
The compact
aluminium roller
guide for high
loads and velocities.

Parker Hannifin Corporation
Pneumatic Division - Europe
329
