Page 342 - Brass, Composite and Thermoplastic Fittings and Valves

Catalog 3501E

Ball Valves 6000 PSI Female-Female Pipe Ends V500HP-X H

PIPE
PART
FLOW
B
THREAD
C
M
N
H
L
NO.
[NPT]
CODE CAP
V500HP-4 1/4-18 .69 1.38 4.50 1.44 2.75 2.94 DIA. D RED COLOR
.240
N
V500HP-6 3/8-18 .56 1.50 4.50 1.69 2.88 3.06 .390 D
C
V500HP-8 1/2-14 .75 1.63 4.50 1.88 3.38 3.19 .510 SQUARE
V500HP-12 3/4-14 .69 2.25 7.00 2.41 3.81 4.69 .790
V500HP-16 1-11.5 .94 2.50 7.00 2.56 4.50 4.94 .950 B L
M
H
6000 PSI Female-Female Pipe Ends
V500HP-X (LARGE) RED COLOR
CODE CAP
PIPE
PART FLOW N
NO. THREAD B C H L M N DIA. D
[NPT] D
C
ROUND
V500HP-20 1 1/4-11.5 .85 3.25 10.00 3.15 4.84 6.31 1.26
V500HP-24 1 1/2-11.5 .99 3.75 10.00 3.35 5.33 6.76 1.50
B L
V500HP-32 2-11.5 1.30 4.50 10.00 3.94 6.54 7.42 1.89 M
6000 PSI Locking-Female-Female Pipe Ends
VP500HP-X H
PART PIPE FLOW RED COLOR
NO. THREAD B C H L M N DIA. D CODE CAP
[NPT]
VP500HP-4 1/4-18 .69 1.38 4.50 1.44 2.75 2.94 .240 N
D
VP500HP-6 3/8-18 .56 1.50 4.50 1.69 2.88 3.06 .390 C
SQUARE
VP500HP-8 1/2-14 .75 1.63 4.50 1.88 3.38 3.19 .510
VP500HP-12 3/4-14 .69 2.25 7.00 2.41 3.81 4.69 .790 B L
M
VP500HP-16 1-11.5 .94 2.50 7.00 2.56 4.50 4.94 .950

6000 PSI Locking-Female-Female Pipe Ends H
VP500HP-X (LARGE)
RED COLOR
CODE CAP
PIPE
PART THREAD B C H L M N FLOW N
NO. [NPT] DIA. D D
C
VP500HP-20 1 1/4-11.5 .85 3.25 10.00 3.15 4.84 6.31 1.26 ROUND
VP500HP-24 1 1/2-11.5 .99 3.75 10.00 3.35 5.33 6.76 1.50
B L
VP500HP-32 2-11.5 1.30 4.50 10.00 3.94 6.54 7.42 1.89
M
