24-15
Front axle-front wheel hub with brake drum assembly

(b) Using puller, remove left front wheel
hub oil seal ring.
• At the same time, take off inner
race of inner tapered roller bearing
of left front wheel hub.

Notice:
Do not reuse removed oil seal ring.

8. Removing left front wheel hub bearing
(a) Take off inner race of inner tapered
roller bearing of left front wheel hub
from left steering knuckle.

(b) Using copper bar, take off outer race of 24
outer tapered roller bearing from left
front wheel hub.

(c) Using copper bar, take off outer race of
inner tapered roller bearing from left
front wheel hub.

9. Removing right front wheel hub oil seal
Tip:
Follow the same removal steps for left front wheel hub oil seal to remove right front wheel hub oil seal.
10. Removing right front wheel hub bearing
Tip:
Follow the same removal steps for left front wheel hub bearing to remove right front wheel hub
bearing.
