24-11
Front Axle-Front Wheel Hub Bearing

(d) Remove left front wheel and tire

assembly. (Reference “Chapter 23
Wheels and Tires-Front Wheel and Tire
Assembly, Replacement”.)

(e) Secure a dial indicator to the bracket and
allow it to come into contact with side

face of left front wheel hub.
(f) Push and pull left front wheel hub
horizontally to check for displacement.
Tip:
There should be no displacement, otherwise

replace with a new left front wheel hub bearing.
(Reference “Chapter 24 Front Axle-Front Wheel
Hub with Brake Drum Assembly, Overhaul”.)

24
3. Checking right front wheel hub bearing clearance
Tip:
Follow the same steps for checking left front wheel hub bearing clearance to check right front wheel
hub bearing clearance.
