Tools for threads
Thread former

Synchronous machine thread former HSSE-PM TiN
for universal use up to 1300 N/mm 2
Metal cutting tools
Metal cutting tools
CNC/conv.
M HSSE- TiN
3xd PM C (2-3)
Application: ƒ Ident. No. 220–260: With transition-fit shank and
For manufacturing metric threads in through holes oil grooves.
and blind holes on CNC and conventional machines
in the steel, stainless steel and NF metal material Advantage:
groups up to a strength of 1300 N/mm with > 10% ƒ Innovative mould geometry ensures very high
2
material expansion. dimensional accuracy and process reliability.
ƒ High-quality, torsion-resistant HSSE PM cutting
Execution: material and surface finish for very high service life
ƒ Ident. No. 130–200: With reinforced shank and requirements.
oil grooves. ƒ Short guide component reduces friction.
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13393130-200 30 25 10 10 7 26 38 20 30 18 25
13393220-260 30 25 10 10 7 26 38 20 30 18 25
Cutting material HSSE-PM
Surface TiN
Tolerance of screw taps ISO 2 (6H)
Lead angle shape C
Application type/machine type CNC,
Conventional
Coolant supply External
DIN 13393...
Ident. No.
mm mm mm mm mm
M3 0.5 2.8 56 6 4.9 Similar to 371 130 O. R.
M4 0.7 3.7 63 6 4.9 Similar to 371 140 O. R.
M5 0.8 4.65 70 6 4.9 Similar to 371 150 O. R.
M6 1 5.55 80 6 4.9 Similar to 371 160 O. R.
M8 1.25 7.4 90 8 6.2 Similar to 371 180 O. R.
M10 1.5 9.3 100 10 8 Similar to 371 200 O. R.
M12 1.75 11.2 110 12 9 Similar to 376 220 O. R.
M14 2 13.1 110 14 11 Similar to 376 240 O. R.
M16 2 15 110 16 12 Similar to 376 260 O. R.
Unit price, €
Prod. Gr. 131
Machine thread former HSSE Carbo
for universal use up to 1300 N/mm 2 DIN 2174

CNC/conv.
M HSSE- CARBO
1xd PM C (2-3) Ident. No. 021–100
Application: ƒ High-quality, torsion-resistant HSSE PM cutting
For manufacturing metric threads in through holes material and surface finish for very high service life
and blind holes on CNC and conventional machines requirements.
in the NF metal material group up to a strength of ƒ Cutting edge finish for very high service life Ident. No. 130–180
1300 N/mm with a material expansion of > 10%. requirements.
2
Execution: ƒ Innovative carbo coating for very good gliding prop-
erties and emergency operating function if coolant
ƒ With reinforced shank and oil grooves. supply is interrupted.
Advantage:
ƒ Innovative mould geometry ensures very high
dimensional accuracy and process reliability.
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13398021-100 40 50 35 45 27 32
13398130-180 40 50 35 45 27 32
Cutting material HSSE-PM HSSE-PM
Surface CARBO CARBO
Tolerance of screw taps ISO 2X ISO 3X
(6HX) (6GX)
Lead angle shape C C
Application type/machine type CNC, CNC,
Conventional Conventional
Coolant supply External External
DIN 13398... 13398...
Ident. No. Ident. No.
mm mm mm mm mm
M2 0.4 1.8 45 2.8 2.1 Similar to 371 | 021 O. R. - -
2174
M2.5 0.45 2.3 50 2.8 2.1 Similar to 371 | 025 O. R. - -
2174
M3 0.5 2.8 56 3.5 2.7 Similar to 371 | 031 O. R. 130 O. R.
2174

www.buypremiumtools.com 188
