Tools for threads
Thread milling cutter

Nominal Ø Pitch (mm) l1 (mm) l2 (mm) ls (mm) ds (mm) Shaft Ø (mm) Number of fz steel 13496...
(mm) cutting edges 1000 ˜ (mm) Ident. No.
(PCS)
8 1.25 74 21.85 22.8 9 10 3 0.05 280 O. R.
Metal cutting tools
Metal cutting tools
10 1.5 80 26.2 27.4 11 12 4 0.06 300 O. R.
12 1.75 90 32.3 33.7 13.5 14 4 0.07 320 O. R.
16 2 102 42.95 44.6 17.5 18 4 0.1 360 O. R.
Unit price, €
Prod. Gr. 132
Holder for thread milling cutter, single cutter
for use of thread milling cutter plates

HB HA
IK
Application: ƒ Ident. No. 065–085: Solid carbide steel tool ƒ Ident. No. 005–060, 090–105: High-quality
For using ground thread milling cutter inserts no. holder with one insert seat carrier material for very high service life
13397. ƒ Ident. No. 090–105: Burnished steel tool holder requirements
Execution: with two insert seats ƒ Ident. No. 065–085: High quality solid carbide
carrier material for very high requirements in
ƒ Ident. No. 005–060: Burnished steel tool holder Advantage: terms of service life and low vibration
with one insert seat ƒ High process reliability and dimensional accuracy ƒ Ident. No. 090–105: High machining speed due to
due to precise insert seating two-tip geometry
d2 d2
d1 d1 d1
lp lp
l1 lp
l2 l2
l1 l1
Ident. No. 005–060 Ident. No. 065–085 Ident. No. 090–105
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13397005-060 140 130 100 120 100 240 240 220 220 200 200 220 90 60 50 50
13397065-085 140 130 100 120 100 240 240 220 220 200 200 220 90 60 50 50
13397090-105 140 130 100 120 100 240 240 220 220 200 200 220 90 60 50 50
Suitable for Cutting edge d1 (mm) Suitable for min. Shaft Ø (mm) l1 (mm) l2 (mm) Tool holding 13397...
indexable insert length (mm) Ø (mm) device Ident. No.
size
12 12 9.5 12.2 20 85 14 HB parallel 005 O. R.
shank
12 12 9.9 12.8 20 85 16 HB parallel 012 (O. R.)
shank
14 14 12 15.5 20 75 20 HB parallel 015 O. R.
shank
14 14 14.5 18.7 20 85 25 HB parallel 022 O. R.
shank
14 14 17 21.9 20 85 30 HB parallel 025 O. R.
shank
21 21 18 23.2 20 85 30 HB parallel 032 O. R.
shank
21 21 21 27.1 20 94 40 HB parallel 035 O. R.
shank
21 21 25 32.3 20 125 - HB parallel 042 O. R.
shank
30 30 29 37.4 25 110 50 HB parallel 045 O. R.
shank
30 30 31 40 25 150 - HB parallel 052 O. R.
shank
30 30 38 49 32 150 - HB parallel 055 O. R.
shank
40 40 48 61.9 40 153 78 HB parallel 060 O. R.
shank
12 12 9.9 12.8 8 125 - HA parallel 065 (O. R.)
shank
14 14 13.2 17.0 10 150 - HA parallel 070 (O. R.)
shank
14 14 15.2 19.7 12 175 - HA parallel 075 (O. R.)
shank
21 21 21 27.1 16 200 - HA parallel 080 (O. R.)
shank
30 30 27 35 20 270 - HA parallel 085 (O. R.)
shank
14 14 20 26 20 93 41 HB parallel 090 (O. R.)
shank
21 21 30 39 25 108 52 HB parallel 095 (O. R.)
shank
30 30 40 52 32 130 70 HB parallel 100 (O. R.)
shank
40 40 50 65 40 153 78 HB parallel 105 (O. R.)
shank
Unit price, €
Prod. Gr. 132
