Page 201 - Buy Premium Tools ATORN Catalogue

Tools for threads
Thread cutting sets

Machine tap set DIN 376
in through hole and blind hole
Metal cutting tools
Metal cutting tools
M HSSE
2,5xd
Application: ƒ Ident. No. 045: Machine tap set, comprising
Ident. No. 015: For producing metric threads on HSSE-TiN 13246 + 13052 for M3, M4, M5, M6, M8,
CNC machines or conventional machines in blind M10, M12
holes and through holes, in steel, (stainless steel),
non-ferrous metals and (cast iron) material groups Advantage:
up to a strength of 1000 N/mm . 2 ƒ Innovative cutting geometry and coating ensure
Ident. No. 045: For producing metric threads on high process reliability
CNC machines or conventional machines in through ƒ Universal use for maximum application flexibility
holes, in steel, (stainless steel), non-ferrous metals ƒ Robust metal box protects the tool from damage
and cast iron material groups up to a strength of and contamination
1300 N/mm . 2 ƒ Ident. No. 045: High-quality, torsion-resistant
Execution: cutting material and cutting edge treatment for
very high service life requirements
ƒ Ident. No. 015: Machine tap set, comprising HSSE
13113 + 13117 + 13281 for M3, M4, M5, M6, M8,
M10, M12
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13401015 14 10 8 18 18 15 18 15 15 13 16
13401045 17 11 10 9 11 19 19 17 19 17 17 15 16 18
Composition of set 1 of each machine tap M3/M4/M5/M6/M8/ 1 of each machine tap M3/M4/M5/M6/M8/
M10/M12 for through holes and blind holes M10/M12 for through holes and blind holes
Cutting material HSSE HSSE
Colour ring system Steels UNI
015
045
Ident. No.
13401... Set price, € O. R. O. R.
Prod. Gr. 131
Machine tap set + core drill DIN 376
in through hole and blind hole

M HSSE
2,5xd
Application: ƒ Ident. No. 035: Machine tap set, comprising HSSE
Ident. No. 025: For producing metric threads on 13130 + 13306 and core drill no. 11029 for M3,
CNC machines or conventional machines in blind M4, M5, M6, M8, M10, M12
holes and through holes, in steel, (stainless steel),
non-ferrous metals and (cast iron) material groups Advantage:
up to a strength of 1000 N/mm . 2 ƒ Innovative cutting geometry and coating ensure
Ident. No. 035: For producing metric threads on high process reliability
CNC machines or conventional machines in blind ƒ Robust metal box protects the tool from damage
holes and through holes, in the high-strength steel and contamination
material group up to a strength of 1300 N/mm . 2 ƒ Ident. No. 025: Universal use for maximum appli-
cation flexibility
Execution: ƒ Ident. No. 035: Specialised use with optimised
ƒ Ident. No. 025: Machine tap set, comprising HSSE chip geometry for use in high-strength steel
13113 + 13117 + 13281 and core drill no. 11020 for
M3, M4, M5, M6, M8, M10, M12
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
13401025 14 10 8 18 18 15 18 15 15 13 16
13401035 15 10 9
Composition of set 1 of each HSSE 13113 + 13117 + 13281 1 of each HSSE 13130 + 13306 machine
machine tap M3/M4/M5/M6/M8/M10/ tap M3/M4/M5/M6/M8/M10/M12
M12 for through holes and blind holes | 1 for through holes and blind holes | 1 of
of each core drill no. 11020 with diameter each core drill no. 11029 with diameter
2.5/3.3/4.2/5.0/6.8/8.5/10.2 2.5/3.3/4.2/5.0/6.8/8.5/10.2
Cutting material HSSE HSSE
Colour ring system Steels High-strength steels
035
025
Ident. No.
13401... Set price, € O. R. O. R.
Prod. Gr. 131

www.buypremiumtools.com 201
