Milling tools
Solid carbide milling cutter universal machining

Type N
Surface ULTRA
Tool holding device HB parallel
shank
Metal cutting tools
Metal cutting tools
Z (PCS) fz steel 16856...
1000 ˜ (mm) ID no.
mm mm mm mm mm mm mm
10 2 22 30 72 9.2 10 4 0.06 050 O. R.
12 0.2 16 26 73 11 12 4 0.07 051 O. R.
12 0.2 26 36 83 11 12 4 0.07 052 O. R.
12 0.5 26 36 83 11 12 4 0.07 054 O. R.
12 1 16 26 73 11 12 4 0.07 055 O. R.
12 1 26 36 83 11 12 4 0.07 056 O. R.
12 1.5 16 26 73 11 12 4 0.07 057 O. R.
12 1.5 26 36 83 11 12 4 0.07 058 O. R.
12 2 16 26 73 11 12 4 0.07 059 O. R.
12 2 26 36 83 11 12 4 0.07 060 O. R.
16 0.3 22 32 82 15 16 4 0.09 063 O. R.
16 0.3 36 42 92 15 16 4 0.09 064 O. R.
16 1 22 32 82 15 16 4 0.09 065 O. R.
16 1 36 42 92 15 16 4 0.09 066 O. R.
16 2 36 42 92 15 16 4 0.09 068 O. R.
16 4 36 42 92 15 16 4 0.09 070 O. R.
20 1 41 52 104 19 20 4 0.12 080 O. R.
20 2 41 52 104 19 20 4 0.12 082 O. R.
20 4 41 52 104 19 20 4 0.12 084 O. R.
Unit price, €
Prod. group 108
Solid carbide radius milling cutter Milling cutter design standard Company
2 cutters, uncoated standard

Typ Z HB
VHM N 2
Application: ƒ Straight shank in accordance with DIN 6535 HB
Radius milling cutter for universal use for copy mill- ƒ Centre cutting
ing in dip working and mould construction. ƒ With clearance
Execution:
ƒ Solid carbide ultra-fine grain
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16740 85 75 65 45 45 300 350 130 160 110 135 225 100 35 30 30
Type N
Surface Uncoated
Tool holding device HB parallel
shank
Z (PCS) fz steel 1000 ˜ 16740...
(mm) ID no.
mm mm mm mm mm mm
3 5 9 50 2.9 6 2 0.024 030 O. R.
4 8 12 54 3.9 6 2 0.036 040 O. R.
5 9 15 54 4.9 6 2 0.045 050 O. R.
6 10 17 54 5.9 6 2 0.054 060 O. R.
8 12 20 58 7.8 8 2 0.072 080 O. R.
10 14 26 66 9.8 10 2 0.084 100 O. R.
12 16 28 73 11.8 12 2 0.096 120 O. R.
16 22 32 82 15.7 16 2 0.12 160 O. R.
Unit price, €
Prod. group 108
