Solid carbide milling cutter universal machining

Solid carbide radius milling cutter Milling cutter design standard Company
2 flutes, uncoated / ULTRA - coated standard
Metal cutting tools
Metal cutting tools
Typ Z HB
VHM ULTRA N 2
Application: ƒ From 6 mm diameter straight shank in accordance No. 16744
Radius milling cutter for universal use for copy mill- with DIN 6535 HB
ing in dip working and mould construction. ƒ Centre cutting
Execution: ƒ No. 16744: Uncoated No. 16745
ƒ Solid carbide ultra-fine grain ƒ No. 16745: ULTRA-coated
ƒ Up to 5 mm diameter straight shank in accordance
with DIN 6535 HA
Application Steel (N/mm ) Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
2
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16744030-050 70 65 55 40 40 255 300 110 135 95 115 190 85 30 25 25
16744060-200 70 65 55 40 40 255 300 110 135 95 115 190 85 30 25 25
16745030-050 75 70 60 40 40 270 315 120 145 100 120 200 90 30 25 25
16745060-200 75 70 60 40 40 270 315 120 145 100 120 200 90 30 25 25
Type N N
Surface Uncoated ULTRA
Tool holding device HB parallel HB parallel
shank shank
Z (PCS) fz steel 1000 ˜ 16744... 16745...
(mm) ID no. ID no.
mm mm mm mm
3 20 60 3 2 0.02 030 O. R. 030 O. R.
4 30 75 4 2 0.03 040 O. R. 040 O. R.
5 30 75 5 2 0.038 050 O. R. 050 O. R.
6 40 100 6 2 0.045 060 O. R. 060 O. R.
8 40 100 8 2 0.06 080 O. R. 080 O. R.
10 40 100 10 2 0.07 100 O. R. 100 O. R.
12 45 100 12 2 0.08 120 O. R. 120 O. R.
16 65 150 16 2 0.1 160 O. R. 160 (O. R.)
20 75 150 20 2 0.12 200 O. R. 200 O. R.
Unit price, €
Prod. group 108

Solid carbide radius roughing cutter Milling cutter design standard Company
4 flutes, ULTRA coated standard

Typ Z HB
VHM ULTRA
NR 4
Application: ƒ Straight shank in accordance with DIN 6535 HB
Radius roughing cutter for universal machining. ƒ Centre cutting
Execution: ƒ ULTRA coated
ƒ With clearance
ƒ Solid carbide ultra-fine grain
Application Steel (N/mm ) 2 Stainless steel Alu Brass Bronze Plas- Graphite GG(G) Titan- Nickel- Super- Hard mat.
No. <700 <1000 <1300 marten. austen. short long short long short long tics G(C)FK GjMW alloy alloy alloy <55 HRC <65 HRC
16866 90 75 65 45 40 135 120 100
Type NR
Surface ULTRA
Tool holding device HB parallel
shank
Z (PCS) fz steel 1000 ˜ 16866...
(mm) ID no.
mm mm mm mm mm mm
6 13 19 57 5.8 6 4 0.09 060 O. R.
8 19 25 63 7.7 8 4 0.12 080 O. R.
10 22 30 72 9.8 10 4 0.14 100 O. R.
12 26 36 83 11.8 12 4 0.16 120 O. R.
16 32 42 92 15.7 16 4 0.2 160 O. R.
Unit price, €
Prod. group 108
