11.2.6 Diode Check

01. Switch multi-meter function to Diode
02. Connect black probe to Pin1 and red probe to Pin2, then measure the diode value.

03. According to the diode attribution, the measuring should be open when red probe
connect to Pin1 and black probe on pin2.

Figure 11-8: Diode Check

11.3 Oscilloscope

11.3.1 Introduction of SS-7821

DC to 200MHz, 3CH, 8 traces

High-speed auto setup
Save/recall of up to 32 panel settings
Full TV triggering with field and line selection

Maximum sensitivity of 2mV/div, fastest sweep of 2 ns/div
5-digit frequency counters
CH3 sensitivities of 50mV, 100mV, 500mv/div
Cursor measurement values /panel settings readout function -1
