Chief Architect X10 Reference Manual

1 Check Display on All Floors to display
the selected camera’s symbol in floor Note: Callout arrows only display as filled
plan view on all floors. When unchecked, it when a camera is inactive. Inactive camera
only displays on the floor where the camera callout arrows are unfilled.
was created. See “Creating Camera Views”
on page 1049. • Specify the Cross Section Line Style.
Not available when Center is selected,
2 Check Display As Callout to use a above. Check By Layer to use the line
callout symbol to represent the selected style specified for the selected callout’s
camera in floor plan view and enable the layer, or choose a line style from the drop
settings below. Most of the Standard down list or the Library.
Options, below, are unavailable when • Specify the Cross Section Line Weight.
Display as Callout is checked.
Not available when Center is selected,
• Specify the callout Placement, either at above. Check By Layer to use the line
the Center, Left Side, Right Side, or Both weight specified for the selected callout’s
Sides of the clip plane. If Center is layer, type a line weight in the text field.
selected, no clip plane line displays.
• Specify the Callout Label, which is the 3 The Standard Options settings allow
you to specify the appearance of the
text that displays inside the callout circle. selected camera’s standard symbol. Uncheck
If no Text Below Line is specified, the Default beside any of these options to
Callout Label is centered in the callout. modify it. Most of these options are disabled
• Specify the Text Below Line for a bot- when Display As Callout is unchecked. See
tom row of text, if desired. Check Auto- “Dynamic Defaults” on page 88.
matic to populate the Text Below Line • The Camera Symbol Size is measured in
with the layout page Label if the selected plan inches (mm).
view is sent to layout. If no layout page
Label is specified, no automatic Text • Check Show Camera Focal Point to dis-
Below Line will be created. See “Camera play the camera’s focal point in floor plan
Labels and Callouts” on page 1058. view. When unchecked, the camera’s line
of sight, focal point, and clip plane indi-
• To specify the Callout Size, uncheck cators are hidden until the camera is
Automatic and then type in the text field. selected.
When Automatic is checked, the size is
based on the length of the Callout Label • Specify the Clip Plane Indicator
and the size of the current Text Style. Length in plan inches (mm). See “To cre-
ate a Cross Section/Elevation view” on
• Specify the appearance of the Callout page 1053.
Arrow. Choose None, a Small arrow, or
a Large arrow. Uncheck Filled if you do Backdrop Panel
not want a solid filled arrow.
The settings on the BACKDROP panel allow
you to specify a backdrop image or color to

1084
