Chief Architect X10 Reference Manual

The settings in this dialog are also found in dialogs. See “Camera Defaults Dialogs” on
the Cross Section/Elevation, Backclipped page 1043.
Cross Section, and Wall Elevation Defaults

Camera Panel

1 The Camera Name displays in floor • Check Ray Casted Sun Shadows for
plan view and is listed in the Project higher quality shadows cast by sun light.
Browser. See “Project Browser” on page 75. Ray Casted Sun Shadows take longer to
• Check Saved to save this view with the generate than regular shadows and only
plan. As soon as you type anything in the refresh when the camera is not moving.
text field, this box becomes checked. If • Check Edge Smoothing When Idle to
you click OK while this box is checked, it apply high quality smoothing to edge and
will become checked permanently. Saved pattern lines when the camera is not in
cameras are listed in the Project Browser. motion. See “Edge Smoothing” on page
• Select the selected camera’s Rendering 1089.
Technique from the drop-down list. See Settings in the Positioning section
“Rendering Techniques” on page 1106. 2 determine the location of the camera in
• Check Show Shadows to turn on shad- floor plan view.
ows in the selected camera view. When • Specify the X Position of the camera in
unchecked, shadows are not generated. absolute coordinates.
See “Shadows” on page 1088.
• Specify the Y Position of the camera in
absolute coordinates.

1082
