Cross Section/Elevation Camera Specification Dialog

display behind your model in the selected 3D LABEL panel are limited to the Suppress
view. See “Backdrop Panel” on page 1080. Label checkbox and Position and
Orientation settings.
Layer Panel
Camera labels always use the Camera Name
The setting on the LAYER panel lets you specified on the CAMERA panel. When
choose which layer the selected camera’s callouts are used, the Callout Label and
plan view symbol is placed on. For more Text Below Line are specified on the Plan
information, see “Layer Panel” on page 195. Display panel.
For information about this panel, see “Label
Label Panel Panel” on page 682.

In the Cross Section/Elevation Camera
Specification dialog, the settings on the

1085
