Chief Architect X10 Reference Manual

To change a setting below, first uncheck
Default. See “Dynamic Defaults” on page You can increase a camera’s Field of
88. View when the view is active by press-
ing the W key, or decrease the Field of View
• The Incremental Move Distance con- by pressing the N key.
trols how far the camera moves each time
you Pan in any direction or Dolly for- Options -
wards or backward using the keyboard, 4
toolbar buttons, or menu. For interior • Clip Surfaces Within - Objects located
views a small number is good, but for within this distance from the camera do
exterior you may want a larger increment.
not display in the view. Decrease this
• The Incremental Rotate Angle defines value to display objects located very
how many degrees the camera rotates close to the camera; increase it to
each time you Tilt, Orbit, or Dolly side to improve the appearance of some surfaces
side using the keyboard, toolbar buttons, in Overview cameras with very large
or menu. A setting of 90° would make extents.
one full rotation in four moves.
• Uncheck Show Lower Floors to show
• The Field of View defines the camera’s only the current floor in the selected
field of vision in angular degrees. See Floor Overview. When checked, the cur-
“Field of View” on page 1069. rent floor plus any floors beneath it are
included in the view. Only available for
Floor Overviews. See “Floor Overview”
on page 1050.

Plan Display Panel
The settings on the PLAN DISPLAY panel in floor plan view. See “In Floor Plan View”
control the appearance of the selected camera on page 1057.

1078
