BW - 42 Body - Windshield, window glass, rearview mirror

Technical parameter Relay
Torque requirement

Tighten the part N•m

Fixing bolts for door hinges 28~32
Fixing bolts for door lock catch 23~27

Door glass rail mounting bolt 6~9

Door glass mounting bolt 6~9

Glass lifter mounting bolt 6~9

Front lower view mirror mounting bolt 10~12
Side lower view mirror mounting bolt 10~12

Rearview mirror mounting bolt 10~12

Door inspection
1. General inspection
a. Inspect the door glass lifter handle for smooth operation; if any, replace the handle or or lubricate the lifter.

b. Inspect the door glass lifter operation for abnormal noise; if any, it may be generally caused by inadequate
lubrication on the glass lifter, it should be removed for re-lubrication.
2. If the door is damaged, it should be inspected as follows
a. Inspect the lifter for deformation; if any, repair or replace it.

b. Inspect the glass rail for deformation; if any, repair or replace it.

BW-042
