Body - Windshield, window glass, rearview mirror BW - 55

Change IN
1. Remove the rear windshield
DI
a. Place the glass suction disc onto the rear windshield and
turn the switch on the suction disc on, to ensure that the
suction disc can suck the windshield. EG

Warning
Because the glass is heavy and easy to break, it is TR
necessary to have one or two assistants to dismount and
install it to ensure the safety.
AX
b. Enter the cab, pry off the seal edge arould the glassm and
push out the glass and glass seal. FR

Caution
Must hold the glass carrier by one or two persons ST
outside the cab, to prevent the glass from falling off.

BR

BW

2. Install the rear windshield
a. Install the rear windshield seal onto the rear windshield. EL

Caution
Do not damage the glass or distort the glass seal. If the
glass seal is difficult to install, heat it.

b. Pass a rope with diameter of 5 ~ 6mm into the
rear windshield seal; wrind the rope one turn and overlap it
both ends at the lower center of the glass.

BW-055
