EL - 114 Electrical system – electrical components
IN
b. Put the A/C control switch into the mounting place.
DI Tighten the fixing screws for the A/C control switch.
Caution
EG Sort the harness before installing the A/C control switch.
TR
AX
6. Install the control panel assembly (refer to “Chapter BW Vehicle Body- Instrument Panel,
Combination Instrument, Ashtray - Instrument panel, Replacement”)
FR
7. Connect the cable of battery negative pole
