Electrical system – electrical components                EL - 121

                                                                                                                  IN

                                                        b.  Mount  and  tighten  the  right  fixing  screw  for  the
                                                        instrument panel air duct assembly.                       DI

                                                                                                                  EG


                                                                                                                  TR

                                                                                                                  AX

                                                        c. Mount and tighten the left fixing screw for the instrument
                                                        panel air duct assembly.
                                                                                                                  FR


                                                                                                                  ST


                                                                                                                  BR


                                                                                                                  BW
              5.  Install  the  instrument  panel  assembly  (refer  to  “Chapter  BW  Vehicle  Body-  Instrument  Panel,

              Combination Instrument, Ashtray - Instrument panel, Replacement”)
