Engine section – Engine (Cummins ISF3.8) EG - 135

Change IN

1. Disassemble oil supply pipe - fuel tank to strainer
DI
a. Disassemble the connector nuts of the oil outlet pie of the
fuel tank.
EG

TR

AX

b. Disassemble the swing bolts and gaskets of the oil inlet
pipe of the diesel filter. FR
c. Cut the plastic fastening belt and cable tie of the oil pipe
and remove the oil supply pipe- fuel tank to strainer. ST

BR

BW

2. Disassemble the fuel supply - strainer to oil pump

a. Disassemble the swing bolts and gaskets of the oil outlet EL
pipe of the diesel filter.

b. Disconnect the connectors of the oil inlet pipe of the oil
pump.
c. Cut the plastic fastening belt and cable tie of the oil pipe
and remove the oil supply pipe- strainer to oil pump.

EG-135
