EG - 142 Engine section – Engine (Cummins ISF3.8)

Diesel filter

change
1. Park the car on a steady ground, stop the engine, turn the ignition switch off, place the transmission
in neutral gear and start the parking brake system.
2. Disassemble the diesel filter

a. Disconnect the connectors of the oil inlet pipe and the oil
outlet pipe of the diesel filter.

b. Disassemble the fixing bolts of the diesel filter and
remove the diesel filter.

3. Install the diesel filter

a. Install the diesel filter on the engine, install the fixing
bolts and tighten them.
Torque: 45~59N•m

b. Connect the connectors of the oil inlet pipe and the oil
outlet pie of the diesel filter.

EG-142
