Axles, Transmission Shafts - Rear Axle AX-51
IN
j. Connect the transmission shaft assembly to the rear
axle, install the fixing bolts and nuts and tighten them.
DI
EG
TR
AX
k. Lift the rear of the vehicle to remove the bracket or safety stool.
l. Install the rear wheel assembly. (See Chapter FR Frame, Suspension and Wheels - Wheels and Tires - Rear
FR
Wheels and Tires, Replacement)
m. Fill the rear axle gear oil. (See Chapter AX Axles, Transmission Shafts - Rear Axle / Rear Axle - Rear Axle
- Gear Oil, Replacement) ST
BR
BW
EL
AX-051
