61-40 HEATER AND AIR CONDITIONING - A/C PIPE
(c) Remove the pipe between the expansion
valve and the compressor.
61
(d) Unscrew the retaining bolts of the high
pressure pipe.
(e) Remove the high pressure pipe.
5 . Install the A/C Low Pressure Pipe
(a) Install the high pressure pipe.
