316 grade stainless steel, ensuring a high level of resistance to chemical attack. A square
pitched left hand propeller is included with the mixer, providing a significant amount of
flow per horsepower. Standard models include air, electric, explosion proof motors.
For more details see www.MixerDirect.com or call 812-202-4047.

Looking for
Stainless
Steel Tanks?
See Page 30

Mixer
Stands?
See Page 3

ECM075AGD ECM033EGD ECM033VGD

Part # Name Impeller Impeller Shaft Shaft Shaft Price
Diameter Qty Diameter Length Speed
(in.) (in.) (in.) (rpm)
ECM075AGD 3/4 HP Air Gear Drive 7 1 0.625 32 0-600 $2,330.00
ECM150AGD 1.5 HP Air Gear Drive 8 1 0.625 36 0-600 $2,352.00
ECM400AGD 4 HP Air Gear Drive 8 2 0.75 48 0-600 $2,413.00
ECM033EGD 1/3 HP Electric Gear Drive 7 1 0.625 32 350 $1,536.00
ECM050EGD 1/2 HP Electric Gear Drive 8 1 0.625 32 350 $1,634.00
ECM075EGD 3/4 HP Electric Gear Drive 7 2 0.625 36 350 $1,853.00
ECM100EGD 1 HP Electric Gear Drive 8 2 0.75 48 350 $2,050.00
ECM033XGD 1/3 HP Explosion Proof Gear Drive 7 1 0.625 32 350 $1,803.00
ECM050XGD 1/2 HP Explosion Proof Gear Drive 8 1 0.625 32 350 $1,893.00
ECM075XGD 3/4 HP Explosion Proof Gear Drive 7 2 0.625 36 350 $2,105.00
ECM100XGD 1 HP Explosion Proof Gear Drive 8 2 0.75 48 350 $2,315.00
ECM033VGD 1/3 HP Variable Speed Gear Drive 7 1 0.625 32 0-350 $2,640.00
ECM050VGD 1/2 HP Variable Speed Gear Drive 8 1 0.625 32 0-350 $2,746.00
ECM075VGD 3/4 HP Variable Speed Gear Drive 7 2 0.625 36 0-350 $2,972.00
ECM100VGD 1 HP Variable Speed Gear Drive 8 2 0.75 48 0-350 $3,189.00
