DIESEL RIGGING

DIESEL RIGGING

DIESEL RIGGING 2.0L ENGINE RIGGING KITS 2.0L RIGGING KIT - DTS INBOARD

2.0L RIGGING KIT - MECHANCIAL ALPHA

8M0106705
Rigging kit includes VIP panel, 20 foot power harness, 10 foot vessel extension
harness, fuel level harness, e‑stop harness, diagnostic port and harness, inboard
8M0106703 harness, fuel filter, sea water filter, thru hull fitting and hose
Rigging kit includes VIP panel, 20 foot power harness, 10 foot vessel extension 2.0L Diesel DTS Inboard
harness, fuel level harness, e‑stop harness, diagnostic port and harness, fuel filter,
sterndrive harness, transom hardware, helm harness and 4 way junction box 2.0L RIGGING KIT - MECHANICAL INBOARD
2.0L Diesel Mechanical Sterndrive (Alpha)
2.0L RIGGING KIT - MECHANICAL BRAVO

8M0106706
Rigging kit includes VIP panel, 20 foot power harness, 10 foot vessel extension
harness, fuel level harness, e‑stop harness, diagnostic port and harness, inboard
8M0106704 harness, fuel filter, sea water filter, thru hull fitting and hose, helm harness and 4
Rigging kit includes VIP panel, 20 foot power harness, 10 foot vessel extension way junction box.
harness, fuel level harness, e‑stop harness, diagnostic port and harness, fuel filter, 2.0L Diesel Mechanical Inboard
sterndrive harness, transom hardware, helm harness and 4 way junction box.
2.0L Diesel Mechanical Sterndrive (Bravo)
PANELS DTS
2.0L RIGGING KIT - DTS BRAVO
TDI 3.0L 260 HP ENGINE ASSEMBLY KIT - DTS
STERNDRIVE

98-8M0078877
Engine Assembly Kit includes Drive Lube Monitor,MerCathode,Shift Actuator, Fuel
Module, Exhaust Bullhorn, Literature Kit, Vessel Adapter Assembly and Vessel
Sensor Harness.
Must be used with the correct engine during installation
Mercury Diesel TDI 3.0L 260 HP DTS Sterndrive
TDI 4.2L 335 HP ENGINE ASSEMBLY KIT - DTS
STERNDRIVE
8M0106702 98-8M0078875
Rigging kit includes VIP panel, 20 foot power harness, 10 foot vessel extension Engine Assembly Kit includes Drive Lube Monitor,MerCathode,Shift Actuator, Fuel
harness, fuel level harness, e‑stop harness, diagnostic port and harness, fuel filter, Module, Exhaust Bullhorn, Literature Kit, Vessel Adapter Assembly and Vessel
sterndrive harness, transom hardware and shift plate Sensor Harness.
2.0L Diesel DTS Sterndrive (Bravo) Must be used with the correct engine during installation
Mercury Diesel TDI 4.2L 335 HP DTS Sterndrive
TDI 4.2L 370 HP ENGINE ASSEMBLY KIT - DTS
STERNDRIVE
98-8M0078873
Engine Assembly Kit includes Drive Lube Monitor,MerCathode,Shift Actuator, Fuel
Module, Exhaust Bullhorn, Literature Kit, Vessel Adapter Assembly and Vessel
Sensor Harness.
Must be used with the correct engine during installation
Mercury Diesel TDI 4.2L 370 HP DTS Sterndrive
