26-14
Rear axle- rear wheel brake

Series dual-chamber brake valve

Replacement

1. DIsconnect battery negative pole cable
2. Remove combination meter assembly (refer to “chapter 73 instrument
desk/meter/cigar lighter-instrument panel, replacement”)
3. Remove instrument panel installationcrossbeam welding assembly (refer to “chapter
51 heater and air conditioning-heater housing assembly, overhaul”)
4. Disconnect the connector from clutch switch (refer to “chapter 32 clutch-clutch pedal,
replacement”)
5. Disconnect the connector from brake lamp switch (refer to “chapter 26 service
brake-brake pedal, adjustment”)
6. Drain clutch fluid
7. Disconnect clutch master cylinder oil
inlet pipe
(a). Loosen the clutch master cylinder oil
inlet pipe hoop with a screw-driver and
disconnect the clutch master cylinder oil
inlet pipe.
Notice:
Use a dedicated container to recover the
clutch fluid remained; don’t make it stick to
painted surface, wash the fluid off with a
large amount of water immediately if it comes
into contact with the skin.
26

8. Disconnect clutch master cylinder oil
outlet pipe
(a). Loosen the adapter nuts of clutch master
cylinder oil outlet pipe, disconnect the
clutch master cylinder oil outlet pipe.
