26-18
Rear axle- rear wheel brake

(b). Screw down the 2 connecting bolts of the
pedal suspension and the cab floor.
Torque: 73 ～ 89 N•m
Notice:
There are too many wiring harnesses in this
part, be careful not to break or damage them.

14. Connect the air pipe of series
dual-chamber brake valve
(a). Connect the 2 air pipes of the series dual
-chamber brake valve and the air
pressure gauge according to the
matchmarks and screw down the
terminal nuts of the air pipes.
Torque: 25 ～ 30 N•m

(b). Connect the 4 air pipes of the series dual
-chamber brake valve and screw down
the terminal nuts of the air pipes.
Torque: 25 ～ 30 N•m
