31B-25
Transmission 6g120 - transmission assy

(g). Measure the internal diameter of the
secondary-axle rear bearing.
Internal diameter
Model
Standard Limit
6G120 45 mm 44.988~40 mm

7. Remove the backward gear
(a). Loosen the 8 fixing bolts of the reverse gear
shaft cover and disassemble the reverse gear
shaft cover.

(b). Loosen the locking plate of the reverse gear
shaft.
(c). Punch the reverse gear shaft.
Hint:
Take care not to lose the seal ring.

31B
