Page 903 - Foton Workshop Manual - Auman EST-M

Transmission and Control Mechanism - Manual Transmission TR-89

IN
f. Remove the conical hex plug of the 3rd and 4th gear

shift fork.
DI

EG

TR

g. Remove the interlock pin of the 3rd and 4th gear fork
shaft, and remove the 3rd and 4th gear shift fork. AX
Caution
Gently push out from inside to outside when taking FR
out the fork shaft and push out the plug.

ST

h. Remove the interlock steel balls (two) between the 3rd BR
and 4th gear fork shaft and the 1st and 2nd gear fork

shaft.
BW

EL

i. Remove the hexagonal cone plug of the 1st and 2nd

gear shift knob and fork.

j. Remove the interlock pin of the 1st and 2nd gear fork
shaft, and remove the gear shift knob and fork.
Caution.

Gently push out from inside to outside when taking
out the fork shaft and push out the plug

TR-089
