Axles, Transmission Shafts - Rear Axle AX-75

IN
f. Install the adjustment nut lock washer of hub bearing

and align the notches of rear axle housing with their bolt
holes. DI

EG

TR

AX
g. Install the lock washer fixing bolts and fasten it.
Torque:
FR
Model 16 T 6~12N•m

Model 22T, 25T Lock by bending the lock piece
ST

BR

BW
h. Install the axle shaft and oil seal of axle shaft.(See Chapter FR Axles, Transmission Shafts - Rear Axle /
Rear Shaft - Rear Axle - Rear Axle Shaft , Service)
i. Install the rear wheel assembly.(See Chapter FR Frame, Suspension and Wheels - Wheels and Tires - Rear EL
Wheels and Tires, Replacement)

AX-075
