AX-80 Axles, Transmission Shafts - Rear Axle

f. Pry out the oil seal of diving bezel gear.
g. Remove the driving bezel gear outer bearing

h. Check the bearing for ablation, peeling, pitting and
excessive wear and other defects, if any, replace.
Caution
Replace the bearing with its outer ring together if it is
broken

i. Punch out the outer ring of driving bezel gear bearing.

j. Remove the adjustment shims of driving gear bearing
and spacer from the driving bevel gear.

k. Remove the fixing circlip of driving bevel guide
bearing and pull out the bevel gear guide bearing with
puller.

AX-080
