02 CABLE & WIRE CONNECTION

TERMINAL DISCONNECT

NYLON FULLY INSULATED BULLET DISCONNECTORS
Dimension Packing
Part No Colour Price
W (mm) L (mm) D (mm) B (mm) (pcs/pkt)
WIRE RANGE : 0.5 - 1.5 mm² (AWG 22-16)
MPFNY1 - 156 4.0 27.0 4.0 10.0 100 24.30
D WIRE RANGE : 1.5 - 2.5 mm² (AWG 16-14)
MPFNY2 - 156 4.0 27.0 4.5 10.0 100 24.30

W B Red Blue

L

NYLON FULLY INSULATED DOUBLE BULLET DISCONNECTORS
Dimension
Part No Colour Packing Price
W (mm) L (mm) D (mm) B (mm) (pcs/pkt)
WIRE RANGE : 0.5 - 1.5 mm² (AWG 22-16)
MPFNYD1 - 156 4.0 27.0 4.0 10.0 100 29.80
WIRE RANGE : 1.5 - 2.5 mm² (AWG 16-14)
L W MPFNYD2 - 156 4.0 27.0 4.8 10.0 100 29.80
B
Red Blue

D

VINYL INSULATED DOUBLE CRIMP PIGGY BACK DISCONNECTORS
Dimension
Part No Colour Packing Price
W (mm) L (mm) D (mm) B (mm) (pcs/pkt)
WIRE RANGE : 0.5 - 1.5 mm² (AWG 22-16)
PBDD1 - 250 6.6 22.5 3.8 10.5 100 29.40

WIRE RANGE : 1.5 - 2.5 mm² (AWG 16-14)
D PBDD2 - 250 6.6 22.5 4.7 10.5 100 31.40

WIRE RANGE : 4.0 - 6.0 mm² (AWG 12-10)
PBDD5 - 250 6.6 24.0 6.2 13.0 100 57.00
B
W
L Red Blue Yellow
